ET1 Lipo battery Conversion Connector

for TOKYO MARUI Next Generation Automatic Electric Gun series

QUALITY IS 100% BRAND-NEW GUARANTEED

Manufacturer: ET1 :http://et1.jp

LIMITED WARRANTRY

This warranty is covered the following:

initial failure inside 7days after the purchase.

This warrantry is not covered the following:

damage by inappropriate use

damage and malfunction after the use

use ET1's products with third parties products

damage and malfunction of ET1's conversion connector which used third parties product's batteries

Instruction manual:

Read this manual completely before operationg.

Keep this manual for refaranse after reading.

For your safty, please use with ET1's products.

Avoid the danger, use ET1's products correctly.

Do not use except for method of this manual.

Confirm the polarity, and connect to Electric Guns exactly.

Use with ET1's lipo batteries.

Never disassemble, modify, or repair of this product.

After use, remove from Electric Gun and battery.

Do not get this product wet.

ET1 Lipo battery Conversion Connector Next Generation Automatic Electric Gun

Guide to parts

Cord black( - )

Cord red( + )

Plug (A) : connect on Electric Gun

Plug (B) : connect to battery

Erroneous connection preventive board(ECP board)

CAUTION

Never attach the Plug (A) to opposite direction.

Fuse will open or Electric Gun will break down.

1. Confirm the correct direction of ECP board and connector of Electric Gun.

2. 2. Put the Plug (A) to Electric Gun correct direction.

3. Put lipo battery and balance connector and balance cords into left-hand side pocket.

4. Connect Plug(B) and discharging connector of battery.

5. Put cords and connectors in right-hand side poket. Do not overlap cords to close the stock end cover.

Do not Put this product and battery forcibly to avoid causing the damages.

Left-hand side pocket

Right-hand side pocket

Balance connector

Plug (B) : connect to battery damages.
